Sandvik Coromant 254LKF-16-16-R CoroThread™ 266 boring bar for grooving

Name: Sandvik Coromant 254LKF-16-16-R CoroThread™ 266 boring bar for grooving
SKU: 5961365
Price: 2786.45 ZAR
Availability: InStock

R 2 786,45 inc. vat

In stock

SKU

5961365

CoroThread® 266 boring bar for grooving

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

CoroThread® 266 boring bar for grooving

More Information
CP - Coolant Pressure	4000000Pa
DCON - Connection Diameter	16mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	125mm
BD - Body Diameter	16mm
TQ - Torque	3Nm
WT - Weight Of Item	0.159kg
OAL - Overall Length	125mm
OHX - Maximum Overhang	48mm
LSC - Clamping Length	77mm
KAPR - Tool Cutting Edge Angle	90deg
DMIN - Minimum Bore Diameter	20mm
BAWS - Workpiece Side Body Angle	90deg
OHN - Minimum Overhang	27mm
WF - Functional Width	12mm
HF - Functional Height	0mm
GAMO - Orthogonal Rake Angle	-15deg
LAMS - Inclination Angle	0deg
AN - Clearance Angle Major	0deg
IC - Inscribed Circle Diameter	9.525mm
Insert Thickness	3.96875mm
LU - Usable Length	27mm
CDX - Cutting Depth Maximum	1.3mm
ORDCODE	254LKF-16-16-R
ADINTMS - Adaptive Interface Machine Direction	M_CYLR_G1600_1
CNSC - Coolant Entry Style Code	1
CXSC - Coolant Exit Style Code	3
BMC - Body Material Code	1
CHANGEDATE	2022-08-18 16:09:00.000
MTP - Clamping Type Code	S
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WCOR_TCC16R_1
Hand	L
MIID - Master Insert Identification	254RG-16CC..
IFS - Insert Mounting Style Code	8
SC - Insert Shape Code	T
SSC - Insert Seat Size Code	16
CICT - Cutting Item Count	1
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	False
LOCAP - Location Aid Property	True
