Sandvik Coromant 970-HA10-40-164 HSK to CoroChuckâ„¢ 970
R 34 776,00
inc. vat
In stock
SKU
6412697
HSK to CoroChuck™ 970
Reliable nationwide shipping
Delivery in 4 - 5 days
HSK to CoroChuck™ 970
| CP - Coolant Pressure | 8000000Pa |
|---|---|
| DFC - Functional Diameter | 40mm |
| DCON - Connection Diameter | 40.8mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 146.6mm |
| BD - Body Diameter | 100mm |
| LB - Body Length | 158mm |
| BHTA - Body Half Taper Angle | 0deg |
| RPMX - Rotational Speed Maximum | 80001/min |
| WT - Weight Of Item | 3782g |
| OAL - Overall Length | 207.9mm |
| OHX - Maximum Overhang | 146.6mm |
| ORDCODE | 970-HA10-40-164 |
| ADINTMS - Adaptive Interface Machine Direction | M_HSK01_C1000_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CLTERBT_C0400_1 |
| CNSC - Coolant Entry Style Code | 1 |
| CXSC - Coolant Exit Style Code | 1 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-08-22 13:02:00.000 |
| STDLET - Standard Letter | A |
| STDNO - Standard Number | DIN69893-1 |
| DPC - Damping Property | False |
| DCP - Data Chip Provision | False |
| NROTF - Non Rotating Functionality | False |
| RTOF - Rotating Functionality | True |
