Sandvik Coromant A24T-DSKNL 4 T-Max™ P boring bar for turning
R 5 533,80
inc. vat
Out of stock
SKU
5727613
T-Max® P boring bar for turning
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® P boring bar for turning
| CP - Coolant Pressure | 4000000Pa |
|---|---|
| DCON - Connection Diameter | 38.1mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 304.8mm |
| BD - Body Diameter | 38.1mm |
| TQ - Torque | 3.9Nm |
| WT - Weight Of Item | 2279g |
| OAL - Overall Length | 307.85mm |
| OHX - Maximum Overhang | 152.4mm |
| LSC - Clamping Length | 267.8mm |
| KAPR - Tool Cutting Edge Angle | 75deg |
| RMPX - Maximum Ramping Angle | 0deg |
| DMIN - Minimum Bore Diameter | 44.7mm |
| BAWS - Workpiece Side Body Angle | 0deg |
| BAMS - Machine Side Body Angle | 0deg |
| OHN - Minimum Overhang | 37mm |
| WF - Functional Width | 22.606mm |
| HF - Functional Height | 0mm |
| GAMO - Orthogonal Rake Angle | -6deg |
| LAMS - Inclination Angle | -15deg |
| AN - Clearance Angle Major | 0deg |
| IC - Inscribed Circle Diameter | 12.7mm |
| RE - Corner Radius | 0.79375mm |
| Insert Thickness | 4.7625mm |
| H - Shank Height | 34.9mm |
| LPR - Protruding Length | 307.85mm |
| ORDCODE | A24T-DSKNL 4 |
| ADINTMS - Adaptive Interface Machine Direction | M_CYLF3_S1500_1 |
| CNSC - Coolant Entry Style Code | 1 |
| CXSC - Coolant Exit Style Code | 3 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-06-27 20:51:00.000 |
| MTP - Clamping Type Code | D |
| CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers | WISO_SN1204_1 |
| Hand | L |
| MIID - Master Insert Identification | SNMG 12 04 08 |
| IFS - Insert Mounting Style Code | 2 |
| SC - Insert Shape Code | S |
| SSC - Insert Seat Size Code | 12 |
| CICT - Cutting Item Count | 1 |
| DPC - Damping Property | False |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
