Sandvik Coromant C10-SSRBR-58110-38 CoroTurn™ 107 cutting unit for turning
R 8 855,00
inc. vat
Out of stock
SKU
6273275
CoroTurn® 107 cutting unit for turning
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroTurn® 107 cutting unit for turning
| CP - Coolant Pressure | 4000000Pa |
|---|---|
| DFC - Functional Diameter | 72mm |
| DCON - Connection Diameter | 100mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 110mm |
| TQ - Torque | 18.7Nm |
| WT - Weight Of Item | 5.022kg |
| OAL - Overall Length | 170mm |
| OHX - Maximum Overhang | 110mm |
| KAPR - Tool Cutting Edge Angle | 75deg |
| RMPX - Maximum Ramping Angle | 12deg |
| BAWS - Workpiece Side Body Angle | 0deg |
| BAMS - Machine Side Body Angle | 0deg |
| WF - Functional Width | 58mm |
| HF - Functional Height | 0mm |
| GAMO - Orthogonal Rake Angle | 0deg |
| LAMS - Inclination Angle | 0deg |
| AN - Clearance Angle Major | 5deg |
| IC - Inscribed Circle Diameter | 38.1mm |
| RE - Corner Radius | 3.2mm |
| Insert Thickness | 12.7mm |
| ORDCODE | C10-SSRBR-58110-38 |
| ADINTMS - Adaptive Interface Machine Direction | M_CCS01_C1000_1 |
| CNSC - Coolant Entry Style Code | 3 |
| CXSC - Coolant Exit Style Code | 6 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-06-29 16:36:00.000 |
| STDNO - Standard Number | ISO26623-1 |
| MTP - Clamping Type Code | S |
| CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers | WISO_SB3812_1 |
| Hand | R |
| MIID - Master Insert Identification | SBMT 38 12 32 |
| IFS - Insert Mounting Style Code | 3 |
| SC - Insert Shape Code | S |
| SSC - Insert Seat Size Code | 38 |
| CICT - Cutting Item Count | 1 |
| DPC - Damping Property | False |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
