Sandvik Coromant C3-266RFAZ17039-16 CoroThread™ 266 cutting unit for thread turning

R 4 508,00 inc. vat
Out of stock
SKU
6138421
CoroThread® 266 cutting unit for thread turning
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroThread® 266 cutting unit for thread turning
More Information
CP - Coolant Pressure 4000000Pa
DFC - Functional Diameter 22mm
DCON - Connection Diameter 32mm
KAP - Kappa (z-axis Rot) 180deg
LF - Functional Length 39mm
TQ - Torque 3Nm
WT - Weight Of Item 0.155kg
OAL - Overall Length 58mm
OHX - Maximum Overhang 39mm
BAMS - Machine Side Body Angle 0deg
WF - Functional Width 17mm
HF - Functional Height 0mm
GAMO - Orthogonal Rake Angle -10deg
LAMS - Inclination Angle -1deg
AN - Clearance Angle Major 0deg
IC - Inscribed Circle Diameter 9.525mm
Insert Thickness 3.96875mm
ALP - Axial Clearance Angle -10deg
THCA - Thread Helix Correction Angle 1deg
ORDCODE C3-266RFAZ17039-16
ADINTMS - Adaptive Interface Machine Direction M_CCS01_C0320_1
CNSC - Coolant Entry Style Code 3
CXSC - Coolant Exit Style Code 5
BMC - Body Material Code 1
CHANGEDATE 2022-06-15 15:05:00.000
STDNO - Standard Number ISO26623-1
MTP - Clamping Type Code S
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_TCE16L_2
Hand R
MIID - Master Insert Identification 266.RG-16..
IFS - Insert Mounting Style Code 8
SC - Insert Shape Code T
SSC - Insert Seat Size Code 16
CICT - Cutting Item Count 1
DPC - Damping Property False
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
