Sandvik Coromant C5-570-40-LF Coromant Capto™ to CoroTurn™ SL adaptor

R 6 962,10 inc. vat
In stock
SKU
5729017
Coromant Capto® to CoroTurn® SL adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
Coromant Capto® to CoroTurn® SL adaptor
More Information
CP - Coolant Pressure 7000000Pa
DFC - Functional Diameter 35mm
DCON - Connection Diameter 40mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 46mm
TQ - Torque 17Nm
WT - Weight Of Item 855g
OAL - Overall Length 96mm
OHX - Maximum Overhang 46mm
BAWS - Workpiece Side Body Angle 90deg
WF - Functional Width 21mm
HF - Functional Height 0mm
LPR - Protruding Length 66.3mm
ORDCODE C5-570-40-LF
ADINTMS - Adaptive Interface Machine Direction M_CCS01_C0500_1
ADINTWS - Adaptive Interface Workpiece Direction W_SLHDSA1_C0400_1
CNSC - Coolant Entry Style Code 3
CXSC - Coolant Exit Style Code 1
BMC - Body Material Code 1
CHANGEDATE 2021-11-15 13:13:00.000
STDNO - Standard Number ISO26623-1
Hand L
DPC - Damping Property False
DCP - Data Chip Provision False
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
