Sandvik Coromant LF151.37-2525-024B25 T-Max™ Q-Cut shank tool for face grooving
R 2 674,90
inc. vat
In stock
SKU
5733899
T-Max® Q-Cut shank tool for face grooving
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® Q-Cut shank tool for face grooving
| KAP - Kappa (z-axis Rot) | 0deg |
|---|---|
| LF - Functional Length | 150mm |
| TQ - Torque | 3.2Nm |
| WT - Weight Of Item | 0.677kg |
| OAL - Overall Length | 150mm |
| OHX - Maximum Overhang | 37.7mm |
| LSC - Clamping Length | 112.3mm |
| KAPR - Tool Cutting Edge Angle | 90deg |
| BAWS - Workpiece Side Body Angle | 0deg |
| WF - Functional Width | 26mm |
| HF - Functional Height | 25mm |
| GAMO - Orthogonal Rake Angle | 0deg |
| LAMS - Inclination Angle | 0deg |
| Insert Thickness | 5.287mm |
| H - Shank Height | 25mm |
| CW - Cutting Width | 3mm |
| B - Shank Width | 25mm |
| CDX - Cutting Depth Maximum | 8.7mm |
| DAXN - Minimum Axial Groove Outside Diameter | 30mm |
| DAXX - Maximum Axial Groove Outside Diameter | 35mm |
| ORDCODE | LF151.37-2525-024B25 |
| ADINTMS - Adaptive Interface Machine Direction | M_VKT01_A2525_1 |
| CNSC - Coolant Entry Style Code | 0 |
| CXSC - Coolant Exit Style Code | 0 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-09-01 01:07:00.000 |
| MTP - Clamping Type Code | C |
| CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers | WCOR_CB3F25_1 |
| Hand | L |
| MIID - Master Insert Identification | N151.3-300-25- 7G |
| SSC - Insert Seat Size Code | 25 |
| CICT - Cutting Item Count | 1 |
| AXGSUP - Axial Groove Support Direction | 2 |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
