Major Tech MT1887IS Intrinsically Safe MT1887
The MT1887IS is a True RMS professional multimeter having improved measurement functions, troubleshooting feature, resolution and accuracy to solve problems on power distribution, motor drives, electromechanical equipment and plant automation with the 4-20mA% loop measurements. The meter has a large 40 000 count backlit LCD with the added advantage of a 41 segment analogue bargraph. NCV function, automatic Non-Contact voltage detection, the LCD backlight will be in red when AC voltage above 110V is sensed. Specially designed for the Solar Industry the DC voltage range measures up to 1500V DC, other measuring ranges include ACV to 1000V, Micro Amps and Amps, Frequency, Resistance, Duty Cycle, capacitance and temperature measurements. The Bluetooth function allows the user to transmit data to the Android or iOS mobile App for viewing, organising and sharing recordings. The meter has a double moulded rubber case with IP67 waterproof and dustproof rating, rugged design for heavy duty use.
Accessories:
Temperature Probe
9V Battery
Test Leads
Instruction Manual
Technical Datasheet Instruction Manual
- Intrinsically safe version of the MT1887
- CAT IV 600V and CAT III 1000V
- IP67 Dust & waterproof with O-ring sealed casing
- 40 000 count LCD display with 41 Segment Bargraph
- Measures DC voltage up to 1500V
- Measures AC voltage up to 1000V
- Temperature measurement from -50⁰C to 1000⁰C
- AC & DC Micro Amps up to 10A
- 4-20mA process loop measurements with % reading
- Capacitance to 40mF
- Frequency to 100MHz
- Duty Cycle
- Relative mode
- Automatic non-contact voltage detector above 110V AC, LCD turns red
- Min, Max and Data Hold
- Auto Power Off
