Sandvik Coromant N151.2-400-5F 1125 T-Max™ Q-Cut insert for parting

R 295,55 inc. vat
In stock
SKU
5737372
T-Max® Q-Cut insert for parting
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® Q-Cut insert for parting
More Information
KAP - Kappa (z-axis Rot) 0deg
WT - Weight Of Item 3.6g
BAMS - Machine Side Body Angle 0deg
AN - Clearance Angle Major 7deg
Insert Thickness 8.106mm
CW - Cutting Width 4mm
CWTOLL - Cutting Width Lower Tolerance 0mm
CWTOLU - Cutting Width Upper Tolerance 0.2mm
REL - Corner Radius Left 0.2mm
RER - Corner Radius Right 0.2mm
RETOLL - Corner Radius Lower Tolerance -0.05mm
RETOLU - Corner Radius Upper Tolerance 0.05mm
ORDCODE N151.2-400-5F 1125
CHANGEDATE 2022-06-23 10:21:00.000
Hand N
IFS - Insert Mounting Style Code 7
SSC - Insert Seat Size Code 40
CUTINT_SIZESHAPE - Insert Size And Shape MCOR_CB2G40_1
Grade 1125
COATING PVD TiAlN
SUBSTRATE HC
CBMD - Chip Breaker Manufacturer's Designation 5F
CEDC - Cutting Edge Count 1
