Sandvik Coromant PRDCN 3232P 20 T-Max™ P shank tool for turning

Name: Sandvik Coromant PRDCN 3232P 20 T-Max™ P shank tool for turning
SKU: 5738974
Price: 2432.25 ZAR
Availability: InStock

R 2 432,25 inc. vat

In stock

SKU

5738974

T-Max® P shank tool for turning

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

T-Max® P shank tool for turning

More Information
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	170mm
TQ - Torque	8Nm
WT - Weight Of Item	1.225kg
OAL - Overall Length	170mm
OHX - Maximum Overhang	45mm
LSC - Clamping Length	125mm
RMPX - Maximum Ramping Angle	90deg
BAWS - Workpiece Side Body Angle	0deg
BAMS - Machine Side Body Angle	0deg
WF - Functional Width	26mm
HF - Functional Height	32mm
GAMO - Orthogonal Rake Angle	0deg
LAMS - Inclination Angle	0deg
AN - Clearance Angle Major	7deg
IC - Inscribed Circle Diameter	20mm
RE - Corner Radius	10mm
Insert Thickness	6.35mm
H - Shank Height	32mm
LU - Usable Length	40mm
B - Shank Width	32mm
ORDCODE	PRDCN 3232P 20
ADINTMS - Adaptive Interface Machine Direction	M_VKT01_A3232_1
CNSC - Coolant Entry Style Code	0
CXSC - Coolant Exit Style Code	0
BMC - Body Material Code	1
CHANGEDATE	2022-08-18 15:37:00.000
MTP - Clamping Type Code	P
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WISO_RC2006M_3
Hand	N
MIID - Master Insert Identification	RCMX 20 06 00
IFS - Insert Mounting Style Code	2
SC - Insert Shape Code	R
SSC - Insert Seat Size Code	20
CICT - Cutting Item Count	1
DPC - Damping Property	False
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	False
