Sandvik Coromant PRDCN 5050U 32 T-Max™ P shank tool for turning
R 4 896,70
inc. vat
In stock
SKU
5738979
T-Max® P shank tool for turning
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® P shank tool for turning
| KAP - Kappa (z-axis Rot) | 0deg |
|---|---|
| LF - Functional Length | 350mm |
| TQ - Torque | 17Nm |
| WT - Weight Of Item | 6.109kg |
| OAL - Overall Length | 350mm |
| OHX - Maximum Overhang | 60mm |
| LSC - Clamping Length | 290mm |
| RMPX - Maximum Ramping Angle | 90deg |
| BAWS - Workpiece Side Body Angle | 0deg |
| BAMS - Machine Side Body Angle | 0deg |
| WF - Functional Width | 41mm |
| HF - Functional Height | 50mm |
| GAMO - Orthogonal Rake Angle | 0deg |
| LAMS - Inclination Angle | 0deg |
| AN - Clearance Angle Major | 7deg |
| IC - Inscribed Circle Diameter | 32mm |
| RE - Corner Radius | 16mm |
| Insert Thickness | 9.525mm |
| H - Shank Height | 50mm |
| LU - Usable Length | 55mm |
| B - Shank Width | 50mm |
| ORDCODE | PRDCN 5050U 32 |
| ADINTMS - Adaptive Interface Machine Direction | M_VKT01_A5050_1 |
| CNSC - Coolant Entry Style Code | 0 |
| CXSC - Coolant Exit Style Code | 0 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-05-16 17:04:00.000 |
| MTP - Clamping Type Code | P |
| CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers | WISO_RC3209M_2 |
| Hand | N |
| MIID - Master Insert Identification | RCMX 32 09 00 |
| IFS - Insert Mounting Style Code | 2 |
| SC - Insert Shape Code | R |
| SSC - Insert Seat Size Code | 32 |
| CICT - Cutting Item Count | 1 |
| DPC - Damping Property | False |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
