Sandvik Coromant RAG151.32-D12-M59-25 T-Max™ Q-Cut boring bar for grooving

Name: Sandvik Coromant RAG151.32-D12-M59-25 T-Max™ Q-Cut boring bar for grooving
SKU: 5739277
Price: 3615.60 ZAR
Availability: InStock

Be the first to review this product

R 3 615,60 inc. vat

In stock

SKU

5739277

T-Max® Q-Cut boring bar for grooving

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

T-Max® Q-Cut boring bar for grooving

More Information

More Information
CP - Coolant Pressure	1000000Pa
DCON - Connection Diameter	19.05mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	152.4mm
TQ - Torque	2.2Nm
WT - Weight Of Item	0.272kg
OAL - Overall Length	152.4mm
OHX - Maximum Overhang	76.2mm
LSC - Clamping Length	76.2mm
KAPR - Tool Cutting Edge Angle	90deg
DMIN - Minimum Bore Diameter	15mm
BAWS - Workpiece Side Body Angle	90deg
OHN - Minimum Overhang	48mm
WF - Functional Width	11.5062mm
HF - Functional Height	0mm
GAMO - Orthogonal Rake Angle	0deg
LAMS - Inclination Angle	0deg
Insert Thickness	5.287mm
LU - Usable Length	35.56mm
CW - Cutting Width	2.65mm
CDX - Cutting Depth Maximum	3.9878mm
WB - Body Width	10.5mm
ORDCODE	RAG151.32-D12-M59-25
ADINTMS - Adaptive Interface Machine Direction	M_CYLR_R7500_1
CNSC - Coolant Entry Style Code	1
CXSC - Coolant Exit Style Code	3
BMC - Body Material Code	1
CHANGEDATE	2022-09-01 01:08:00.000
MTP - Clamping Type Code	C
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WCOR_CB3G25_2
Hand	R
MIID - Master Insert Identification	N151.3-265-25- 4G
SSC - Insert Seat Size Code	25
CICT - Cutting Item Count	1
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	False
LOCAP - Location Aid Property	True
