Sandvik Coromant RF151.37-16-034B25 T-Max™ Q-Cut shank tool for face grooving

R 2 674,90 inc. vat
Out of stock
SKU
5741370
T-Max® Q-Cut shank tool for face grooving
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® Q-Cut shank tool for face grooving
More Information
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 152.4mm
TQ - Torque 2.4Nm
WT - Weight Of Item 0.701kg
OAL - Overall Length 152.4mm
OHX - Maximum Overhang 37.7mm
LSC - Clamping Length 114.7mm
KAPR - Tool Cutting Edge Angle 90deg
BAWS - Workpiece Side Body Angle 0deg
WF - Functional Width 26.3906mm
HF - Functional Height 25.4mm
GAMO - Orthogonal Rake Angle 0deg
LAMS - Inclination Angle 0deg
Insert Thickness 5.287mm
H - Shank Height 25.4mm
CW - Cutting Width 3mm
B - Shank Width 25.4mm
CDX - Cutting Depth Maximum 8.7122mm
DAXN - Minimum Axial Groove Outside Diameter 40.0106mm
DAXX - Maximum Axial Groove Outside Diameter 50.0126mm
ORDCODE RF151.37-16-034B25
ADINTMS - Adaptive Interface Machine Direction M_VKT01_B1616_1
CNSC - Coolant Entry Style Code 0
CXSC - Coolant Exit Style Code 0
BMC - Body Material Code 1
CHANGEDATE 2022-09-01 01:08:00.000
MTP - Clamping Type Code C
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_CB3F25_1
Hand R
MIID - Master Insert Identification N151.3-300-25- 7G
SSC - Insert Seat Size Code 25
CICT - Cutting Item Count 1
AXGSUP - Axial Groove Support Direction 2
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
