Sandvik Coromant S06M-STFCR 2 CoroTurn™ 107 boring bar for turning
Next
Sandvik Coromant S08M-STFCR 2 CoroTurn™ 107 boring bar for turning
Previous
![Sandvik Coromant S06M-STFCR 2 CoroTurn™ 107 boring bar for turning](https://toolcentre.co.za/media/catalog/product/cache/3d45c7c636ad12c00ca7e41150c17b7b/image/504223728/sandvik-coromant-s06m-stfcr-2-coroturntm-107-boring-bar-for-turning.jpg)
![Sandvik Coromant S08M-STFCR 2 CoroTurn™ 107 boring bar for turning](https://toolcentre.co.za/media/catalog/product/cache/3d45c7c636ad12c00ca7e41150c17b7b/image/50410c363/sandvik-coromant-s08m-stfcr-2-coroturntm-107-boring-bar-for-turning.jpg)
R 2 178,10
inc. vat
Out of stock
SKU
5752675
CoroTurn® 107 boring bar for turning
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroTurn® 107 boring bar for turning
DCON - Connection Diameter | 9.525mm |
---|---|
KAP - Kappa (z-axis Rot) | 0deg |
LF - Functional Length | 152.4mm |
BD - Body Diameter | 9.525mm |
TQ - Torque | 0.9Nm |
WT - Weight Of Item | 0.1kg |
OAL - Overall Length | 152.4mm |
OHX - Maximum Overhang | 38.1mm |
LSC - Clamping Length | 133.4mm |
KAPR - Tool Cutting Edge Angle | 91deg |
RMPX - Maximum Ramping Angle | 0deg |
DMIN - Minimum Bore Diameter | 12.7mm |
BAWS - Workpiece Side Body Angle | 0deg |
BAMS - Machine Side Body Angle | 0deg |
OHN - Minimum Overhang | 19.05mm |
WF - Functional Width | 6.35mm |
HF - Functional Height | 0mm |
GAMO - Orthogonal Rake Angle | 0deg |
LAMS - Inclination Angle | -15deg |
AN - Clearance Angle Major | 7deg |
IC - Inscribed Circle Diameter | 6.35mm |
RE - Corner Radius | 0.396875mm |
Insert Thickness | 2.38125mm |
H - Shank Height | 8.636mm |
ORDCODE | S06M-STFCL 2 |
ADINTMS - Adaptive Interface Machine Direction | M_CYLF3_R3750_1 |
CNSC - Coolant Entry Style Code | 0 |
CXSC - Coolant Exit Style Code | 0 |
BMC - Body Material Code | 1 |
CHANGEDATE | 2022-04-07 02:12:00.000 |
MTP - Clamping Type Code | S |
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers | WISO_TC1102_2 |
Hand | L |
MIID - Master Insert Identification | TCMT 11 02 04 |
IFS - Insert Mounting Style Code | 3 |
SC - Insert Shape Code | T |
SSC - Insert Seat Size Code | 11 |
CICT - Cutting Item Count | 1 |
DPC - Damping Property | False |
NROTF - Non Rotating Functionality | True |
RTOF - Rotating Functionality | False |
