Sandvik Coromant 400.1-1250-075A1-NM N1BU CoroDrill® 400 solid carbide drill

Name: Sandvik Coromant 400.1-1250-075A1-NM N1BU CoroDrill® 400 solid carbide drill
SKU: 7590111
Price: 5881.10 ZAR
Availability: OutOfStock

Be the first to review this product

R 5 881,10 inc. vat

Out of stock

SKU

7590111

CoroDrill® 400 solid carbide drill

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

CoroDrill® 400 solid carbide drill

More Information

More Information
CP - Coolant Pressure	2000000Pa
DCON - Connection Diameter	14mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	147.49mm
BD - Body Diameter	12.5mm
LB - Body Length	105mm
RPMX - Rotational Speed Maximum	500001/min
WT - Weight Of Item	0.134kg
OAL - Overall Length	150mm
OHX - Maximum Overhang	102.49mm
LSC - Clamping Length	45mm
GAMO - Orthogonal Rake Angle	0deg
LU - Usable Length	75mm
DC - Cutting Diameter	12.5mm
FHA - Flute Helix Angle	0deg
ULDR - Usable Length Diameter Ratio	6
TCHAL - Achievable Hole Tolerance Lower	12.5mm
TCHAU - Achievable Hole Tolerance Upper	12.543mm
PL - Point Length	2.51mm
LCF - Chip Flute Length	100.47mm
SIG - Point Angle	135deg
ORDCODE	400.1-1250-075A1-NM N1BU
ADINTMS - Adaptive Interface Machine Direction	M_CYLRD1_G1400_1
CNSC - Coolant Entry Style Code	4
CXSC - Coolant Exit Style Code	4
BMC - Body Material Code	2
CHANGEDATE	2021-12-22 16:01:00.000
STDLET - Standard Letter	HA
STDNO - Standard Number	DIN6535
Hand	R
TCDCON - Connection Diameter Tolerance	h6
Grade	N1BU
SUBSTRATE	HC
BSG - Basic Standard Group	COROMANT
TCHA - Achievable Hole Tolerance	H9
NOF - Flute Count	2
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	True
