Sandvik Coromant 400.4-1020-063A1-NM N1BU CoroDrill® 400 solid carbide drill
R 5 776,45
inc. vat
Out of stock
SKU
7590153
CoroDrill® 400 solid carbide drill
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroDrill® 400 solid carbide drill
| CP - Coolant Pressure | 2000000Pa |
|---|---|
| DCON - Connection Diameter | 16mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 142.97mm |
| RPMX - Rotational Speed Maximum | 500001/min |
| WT - Weight Of Item | 0.178kg |
| OAL - Overall Length | 145mm |
| OHX - Maximum Overhang | 94.97mm |
| LSC - Clamping Length | 45mm |
| GAMO - Orthogonal Rake Angle | 0deg |
| LU - Usable Length | 63mm |
| DC - Cutting Diameter | 16mm |
| FHA - Flute Helix Angle | 0deg |
| TCHAL - Achievable Hole Tolerance Lower | 10.2mm |
| TCHAU - Achievable Hole Tolerance Upper | 10.243mm |
| PL - Point Length | 2.03mm |
| LCF - Chip Flute Length | 91.57mm |
| SIG - Point Angle | 135deg |
| SDL - Step Diameter Length | 30.6mm |
| STA - Step Included Angle | 90deg |
| ORDCODE | 400.4-1020-063A1-NM N1BU |
| ADINTMS - Adaptive Interface Machine Direction | M_CYLRD1_G1600_1 |
| CNSC - Coolant Entry Style Code | 4 |
| CXSC - Coolant Exit Style Code | 4 |
| BMC - Body Material Code | 2 |
| CHANGEDATE | 2021-12-22 16:01:00.000 |
| STDLET - Standard Letter | HA |
| STDNO - Standard Number | DIN6535 |
| Hand | R |
| TCDCON - Connection Diameter Tolerance | h6 |
| Grade | N1BU |
| SUBSTRATE | HC |
| BSG - Basic Standard Group | COROMANT |
| TCHA - Achievable Hole Tolerance | H9 |
| ZEFP - Peripheral Effective Cutting Edge Count | 2 |
| NOF - Flute Count | 2 |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | True |
