Sandvik Coromant 430.1-1020-070A1-NM N1BU CoroDrill® 430 solid carbide drill
R 4 853,00
inc. vat
Out of stock
SKU
7594063
CoroDrill® 430 solid carbide drill
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroDrill® 430 solid carbide drill
| CP - Coolant Pressure | 2000000Pa |
|---|---|
| DCON - Connection Diameter | 12mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 137.89mm |
| BD - Body Diameter | 10.2mm |
| LB - Body Length | 95mm |
| RPMX - Rotational Speed Maximum | 500001/min |
| WT - Weight Of Item | 0.096kg |
| OAL - Overall Length | 140mm |
| OHX - Maximum Overhang | 92.89mm |
| LSC - Clamping Length | 45mm |
| GAMO - Orthogonal Rake Angle | 20.45deg |
| LU - Usable Length | 70mm |
| DC - Cutting Diameter | 10.2mm |
| FHA - Flute Helix Angle | 30deg |
| ULDR - Usable Length Diameter Ratio | 6.8627450980392 |
| TCHAL - Achievable Hole Tolerance Lower | 10.2mm |
| TCHAU - Achievable Hole Tolerance Upper | 10.243mm |
| PL - Point Length | 2.11mm |
| LCF - Chip Flute Length | 85.3mm |
| SIG - Point Angle | 135deg |
| ORDCODE | 430.1-1020-070A1-NM N1BU |
| ADINTMS - Adaptive Interface Machine Direction | M_CYLRD1_G1200_1 |
| CNSC - Coolant Entry Style Code | 4 |
| CXSC - Coolant Exit Style Code | 4 |
| BMC - Body Material Code | 2 |
| CHANGEDATE | 2022-03-23 18:16:00.000 |
| STDLET - Standard Letter | HA |
| STDNO - Standard Number | DIN6535 |
| Hand | R |
| TCDCON - Connection Diameter Tolerance | h6 |
| Grade | N1BU |
| SUBSTRATE | HC |
| BSG - Basic Standard Group | COROMANT |
| TCHA - Achievable Hole Tolerance | H9 |
| NOF - Flute Count | 3 |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | True |
