Sandvik Coromant 870-2900-29L32-5 CoroDrill® 870 exchangeable tip drill Previous Sandvik Coromant 870-2900-29L32-5 CoroDrill® 870 exchangeable tip drill

Sandvik Coromant 870-2900-29L32-8 CoroDrill® 870 exchangeable tip drill

R 14 433,65 inc. vat
In stock
SKU
6426006
CoroDrill® 870 exchangeable tip drill
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroDrill® 870 exchangeable tip drill
More Information
CP - Coolant Pressure 1000000Pa
DCON - Connection Diameter 32mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 13.82mm
BD - Body Diameter 28.4mm
LB - Body Length 248mm
BHTA - Body Half Taper Angle 0deg
TQ - Torque 3Nm
RPMX - Rotational Speed Maximum 50001/min
WT - Weight Of Item 1.166kg
OAL - Overall Length 334mm
OHX - Maximum Overhang 269.52mm
LSC - Clamping Length 60mm
Insert Thickness 9.86mm
H - Shank Height 30mm
LU - Usable Length 244.45mm
INSL - Insert Length 18.3mm
DC - Cutting Diameter 29.65mm
FHA - Flute Helix Angle 20deg
DCX - Maximum Cutting Diameter 29.99mm
ULDR - Usable Length Diameter Ratio 8.244519392917
PL - Point Length 4.48mm
SIG - Point Angle 142deg
DCN - Minimum Cutting Diameter 29mm
ORDCODE 870-2900-29L32-8
ADINTMS - Adaptive Interface Machine Direction M_CYLISO_G3200_1
CNSC - Coolant Entry Style Code 1
CXSC - Coolant Exit Style Code 3
BMC - Body Material Code 1
CHANGEDATE 2022-01-19 15:05:00.000
MTP - Clamping Type Code C
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_DK29_1
Hand R
MIID - Master Insert Identification 870-2965-29-PM
SSC - Insert Seat Size Code 29
TCDCON - Connection Diameter Tolerance h6
TCHA - Achievable Hole Tolerance H9
CICT - Cutting Item Count 1
NOF - Flute Count 2
DPC - Damping Property False
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality True
