Sandvik Coromant A880-D0750LX25-05 CoroDrill® 880 indexable insert drill Previous Sandvik Coromant A880-D0750LX25-05 CoroDrill® 880 indexable insert drill

Sandvik Coromant A880-D0750P25-03 CoroDrill® 880 indexable insert drill

R 7 884,40 inc. vat
In stock
SKU
5723690
CoroDrill® 880 indexable insert drill
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroDrill® 880 indexable insert drill
More Information
CP - Coolant Pressure 1000000Pa
DCON - Connection Diameter 25.4mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 108.6599mm
BD - Body Diameter 25.4mm
LB - Body Length 61.0108mm
BHTA - Body Half Taper Angle 0deg
TQ - Torque 0.9Nm
RPMX - Rotational Speed Maximum 300001/min
WT - Weight Of Item 0.682kg
OAL - Overall Length 185.242mm
OHX - Maximum Overhang 108.6599mm
LSC - Clamping Length 75.7mm
KAPR - Tool Cutting Edge Angle 88deg
GAMO - Orthogonal Rake Angle 5deg
LAMS - Inclination Angle 0deg
IC - Inscribed Circle Diameter 6mm
Insert Thickness 2.6mm
LU - Usable Length 57.5323mm
ADJLN - Minimum Adjustment Limit 0mm
ADJLX - Maximum Adjustment Limit 0.25mm
DC - Cutting Diameter 19.05mm
FHA - Flute Helix Angle 22deg
ULDR - Usable Length Diameter Ratio 3.02006824147
TCHAL - Achievable Hole Tolerance Lower 0mm
TCHAU - Achievable Hole Tolerance Upper 0.25mm
PL - Point Length 0.3823mm
LCF - Chip Flute Length 72.0408mm
SIG - Point Angle 176deg
ORDCODE A880-D0750P25-03
ADINTMS - Adaptive Interface Machine Direction M_CYLUSP_S1000_1
CNSC - Coolant Entry Style Code 7
CXSC - Coolant Exit Style Code 3
BMC - Body Material Code 1
CHANGEDATE 2022-02-10 15:16:00.000
MTP - Clamping Type Code S
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_DE0303P_1
Hand R
MIID - Master Insert Identification 880-0303W05H-P-GM
IFS - Insert Mounting Style Code 3
SC - Insert Shape Code S
SSC - Insert Seat Size Code 03P
CICT - Cutting Item Count 1
NOF - Flute Count 2
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality True
