Sandvik Coromant HT10-SL40D-208 HSK to CoroTurn™ SL damped adaptor
R 36 446,95
inc. vat
In stock
SKU
7251716
HSK to CoroTurn® SL damped adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
HSK to CoroTurn® SL damped adaptor
| CP - Coolant Pressure | 7000000Pa |
|---|---|
| DFC - Functional Diameter | 75.013mm |
| DCON - Connection Diameter | 40mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 208mm |
| BD - Body Diameter | 40mm |
| LB - Body Length | 176mm |
| BHTA - Body Half Taper Angle | 0deg |
| TQ - Torque | 17Nm |
| WT - Weight Of Item | 4kg |
| OAL - Overall Length | 258mm |
| OHX - Maximum Overhang | 208mm |
| BAWS - Workpiece Side Body Angle | 0deg |
| WF - Functional Width | 0mm |
| HF - Functional Height | 0mm |
| LPR - Protruding Length | 208mm |
| ORDCODE | HT10-SL40D-208 |
| ADINTMS - Adaptive Interface Machine Direction | M_HSK07_C1000_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_SLHDSS_C0400_1 |
| CNSC - Coolant Entry Style Code | 1 |
| CXSC - Coolant Exit Style Code | 1 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-05-23 19:23:00.000 |
| STDLET - Standard Letter | T |
| STDNO - Standard Number | ISO12164-3 |
| Hand | N |
| DPC - Damping Property | True |
| DCP - Data Chip Provision | False |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
