Sandvik Coromant R210-14 05 14E-KM 1020 CoroMill™ 210 insert for milling

R 412,85 inc. vat
In stock
SKU
5742575
CoroMill® 210 insert for milling
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroMill® 210 insert for milling
More Information
KAP - Kappa (z-axis Rot) 0deg
WT - Weight Of Item 12.6g
AN - Clearance Angle Major 7deg
IC - Inscribed Circle Diameter 14.6mm
RE - Corner Radius 1.4mm
Insert Thickness 5.26mm
D1 - Fixing Hole Diameter 5.7mm
LE - Cutting Edge Effective Length 10.83mm
L - Cutting Edge Length 14.5mm
KRINS - Major Cutting Edge Angle 10deg
BS - Wiper Edge Length 0.71mm
APMX - Depth Of Cut Maximum 2mm
BSR - Wiper Edge Radius 50mm
REEQ - Corner Radius Equivalent 3.5mm
ORDCODE R210-14 05 14E-KM 1020
CHANGEDATE 2022-09-23 16:40:00.000
Hand N
IFS - Insert Mounting Style Code 3
SC - Insert Shape Code S
SSC - Insert Seat Size Code 14
CUTINT_SIZESHAPE - Insert Size And Shape MCOR_MA1405_2
Grade 1020
COATING PVD TiAlN
SUBSTRATE HC
CBMD - Chip Breaker Manufacturer's Designation KM
CEDC - Cutting Edge Count 4
WEP - Wiper Edge Property True
