Sandvik Coromant R215.64-32A32-4512 U-Max™ chamfer milling cutter

Name: Sandvik Coromant R215.64-32A32-4512 U-Max™ chamfer milling cutter
SKU: 5742825
Price: 6644.70 ZAR
Availability: InStock

R 6 644,70 inc. vat

In stock

SKU

5742825

U-Max® chamfer milling cutter

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

U-Max® chamfer milling cutter

More Information
DCON - Connection Diameter	32mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	166.5mm
BD - Body Diameter	31.4mm
LB - Body Length	36mm
TQ - Torque	3Nm
RPMX - Rotational Speed Maximum	93851/min
WT - Weight Of Item	1.16kg
OAL - Overall Length	175mm
OHX - Maximum Overhang	36mm
LSC - Clamping Length	138.9mm
KAPR - Tool Cutting Edge Angle	45deg
AN - Clearance Angle Major	11deg
IC - Inscribed Circle Diameter	12.7mm
Insert Thickness	4.7625mm
L - Cutting Edge Length	12.7mm
APMX - Depth Of Cut Maximum	7.86mm
DC - Cutting Diameter	32.5mm
DCX - Maximum Cutting Diameter	48.65mm
ORDCODE	R215.64-32A32-4512
ADINTMS - Adaptive Interface Machine Direction	M_CYLR_G3200_1
CNSC - Coolant Entry Style Code	0
CXSC - Coolant Exit Style Code	0
BMC - Body Material Code	1
CHANGEDATE	2021-11-14 03:38:00.000
MTP - Clamping Type Code	S
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WCOR_NU1204_1
Hand	R
MIID - Master Insert Identification	SPMT 12 04 08-WL
IFS - Insert Mounting Style Code	3
SC - Insert Shape Code	S
SSC - Insert Seat Size Code	12
TCDCON - Connection Diameter Tolerance	h7
CICT - Cutting Item Count	3
ZEFP - Peripheral Effective Cutting Edge Count	3
DPC - Damping Property	False
NROTF - Non Rotating Functionality	False
RTOF - Rotating Functionality	True
LOCAP - Location Aid Property	False
CPDF - Cutting Pitch Differential	False
