Sandvik Coromant R215.H4-10050DAK03P 1620 CoroMill™ Plura solid carbide end mill for High Feed Face milling

R 3 977,85 inc. vat
In stock
SKU
5742569
CoroMill® Plura solid carbide end mill for High Feed Face milling
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroMill® Plura solid carbide end mill for High Feed Face milling
More Information
DCON - Connection Diameter 10mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 150mm
LB - Body Length 26mm
RPMX - Rotational Speed Maximum 146991/min
WT - Weight Of Item 0.18kg
OAL - Overall Length 150mm
OHX - Maximum Overhang 110mm
KAPR - Tool Cutting Edge Angle 32.69deg
RMPX - Maximum Ramping Angle 5deg
RE - Corner Radius 5mm
LU - Usable Length 26mm
APMX - Depth Of Cut Maximum 0.7mm
DC - Cutting Diameter 10mm
DCF - Cutting Diameter Face Contact 3.4mm
FHA - Flute Helix Angle 50deg
GAMF - Radial Rake Angle -18deg
GAMP - Axial Rake Angle 6deg
ULDR - Usable Length Diameter Ratio 2.6
REEQ - Corner Radius Equivalent 1.99mm
ORDCODE R215.H4-10050DAK03P 1620
ADINTMS - Adaptive Interface Machine Direction M_CYLRD1_G1000_1
CNSC - Coolant Entry Style Code 0
CXSC - Coolant Exit Style Code 0
BMC - Body Material Code 2
CHANGEDATE 2022-05-10 17:03:00.000
STDLET - Standard Letter HA
STDNO - Standard Number DIN6535
Hand R
TCDCON - Connection Diameter Tolerance h6
Grade 1620
COATING PVD TiAlN
SUBSTRATE HC
CBMD - Chip Breaker Manufacturer's Designation STRAIGHT
BSG - Basic Standard Group COROMANT
ZEFP - Peripheral Effective Cutting Edge Count 4
NROTF - Non Rotating Functionality False
RTOF - Rotating Functionality True
CCC - Center Cutting Capability False
CPDF - Cutting Pitch Differential False
