Sandvik Coromant 570-40R151.21-32-40 T-Max™ Q-Cut head for grooving Previous Sandvik Coromant 570-40R151.21-32-40 T-Max™ Q-Cut head for grooving

Sandvik Coromant 570-40R151.21-32-50 T-Max™ Q-Cut head for grooving

R 2 244,80 inc. vat
In stock
SKU
5764677
T-Max® Q-Cut head for grooving
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® Q-Cut head for grooving
More Information
CP - Coolant Pressure 1000000Pa
DCON - Connection Diameter 40mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 14mm
BD - Body Diameter 40mm
WT - Weight Of Item 0.149kg
OAL - Overall Length 17.8mm
OHX - Maximum Overhang 14mm
KAPR - Tool Cutting Edge Angle 90deg
BAWS - Workpiece Side Body Angle 90deg
WF - Functional Width 53.6mm
HF - Functional Height 0mm
GAMO - Orthogonal Rake Angle 0deg
LAMS - Inclination Angle 0deg
Insert Thickness 8.106mm
CW - Cutting Width 5mm
CDX - Cutting Depth Maximum 32mm
ORDCODE 570-40R151.21-32-50
ADINTMS - Adaptive Interface Machine Direction M_SLHDS_C0400_1
CNSC - Coolant Entry Style Code 1
CXSC - Coolant Exit Style Code 2
BMC - Body Material Code 1
CHANGEDATE 2022-06-15 14:59:00.000
MTP - Clamping Type Code C
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_CB2G50_1
Hand R
MIID - Master Insert Identification N151.2-500- 5E
SSC - Insert Seat Size Code 50
CICT - Cutting Item Count 1
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
