Sandvik Coromant SL-266LKF-403227-22 CoroThread™ 266 head for thread turning Previous Sandvik Coromant SL-266LKF-403227-22 CoroThread™ 266 head for thread turning

Sandvik Coromant SL-266LKF-403627-27 CoroThread™ 266 head for thread turning

R 6 912,65 inc. vat
In stock
SKU
5750311
CoroThread® 266 head for thread turning
Reliable nationwide shipping
Delivery in 4 - 5 days
CoroThread® 266 head for thread turning
More Information
CP - Coolant Pressure 4000000Pa
DCON - Connection Diameter 40mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 36mm
TQ - Torque 7.5Nm
WT - Weight Of Item 0.154kg
OAL - Overall Length 39.8mm
OHX - Maximum Overhang 36mm
DMIN - Minimum Bore Diameter 50mm
BAMS - Machine Side Body Angle 0deg
WF - Functional Width 26.9mm
HF - Functional Height 0mm
GAMO - Orthogonal Rake Angle -10deg
LAMS - Inclination Angle -1deg
AN - Clearance Angle Major 0deg
IC - Inscribed Circle Diameter 15.875mm
Insert Thickness 7mm
ALP - Axial Clearance Angle -10deg
THCA - Thread Helix Correction Angle 1deg
ORDCODE SL-266LKF-403627-27
ADINTMS - Adaptive Interface Machine Direction M_SLHDS_C0400_1
CNSC - Coolant Entry Style Code 1
CXSC - Coolant Exit Style Code 3
BMC - Body Material Code 1
CHANGEDATE 2022-06-15 14:50:00.000
MTP - Clamping Type Code S
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers WCOR_TCI27L_1
Hand L
MIID - Master Insert Identification 266.LL-27..
IFS - Insert Mounting Style Code 8
SC - Insert Shape Code T
SSC - Insert Seat Size Code 27
CICT - Cutting Item Count 1
DPC - Damping Property False
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
