Sandvik Coromant TNMX 44 09 01-MR 2025 Insert for bar peeling
R 1 163,80
inc. vat
In stock
SKU
5754762
Insert for bar peeling
Reliable nationwide shipping
Delivery in 4 - 5 days
Insert for bar peeling
| KAP - Kappa (z-axis Rot) | 0deg |
|---|---|
| WT - Weight Of Item | 74.7g |
| AN - Clearance Angle Major | 0deg |
| IC - Inscribed Circle Diameter | 25.4mm |
| RE - Corner Radius | 1.5875mm |
| Insert Thickness | 9.525mm |
| D1 - Fixing Hole Diameter | 7.93mm |
| LE - Cutting Edge Effective Length | 14mm |
| L - Cutting Edge Length | 43.9941mm |
| KRINS - Major Cutting Edge Angle | 120deg |
| BSR - Wiper Edge Radius | 25.4mm |
| ORDCODE | TNMX 44 09 01-MR 2025 |
| CHANGEDATE | 2021-12-21 11:03:00.000 |
| Hand | N |
| IFS - Insert Mounting Style Code | 3 |
| SC - Insert Shape Code | T |
| SSC - Insert Seat Size Code | 44 |
| CUTINT_SIZESHAPE - Insert Size And Shape | MISO_TN4409_1 |
| Grade | 2025 |
| COATING | CVD TiCN+Al2O3+TiN |
| SUBSTRATE | HC |
| CBMD - Chip Breaker Manufacturer's Designation | MR |
| CEDC - Cutting Edge Count | 3 |
| WEP - Wiper Edge Property | True |
