Sandvik Coromant 327-16B42EC-14 Weldon to CoroMill™ 327 adaptor

Name: Sandvik Coromant 327-16B42EC-14 Weldon to CoroMill™ 327 adaptor
SKU: 5758732
Price: 5889.15 ZAR
Availability: InStock

R 5 889,15 inc. vat

In stock

SKU

5758732

Weldon to CoroMill® 327 adaptor

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

Weldon to CoroMill® 327 adaptor

More Information
CP - Coolant Pressure	2000000Pa
DCON - Connection Diameter	14.3mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	93.5mm
BD - Body Diameter	14.3mm
LB - Body Length	37.508mm
BHTA - Body Half Taper Angle	30deg
TQ - Torque	6.5Nm
RPMX - Rotational Speed Maximum	400001/min
WT - Weight Of Item	0.245kg
OAL - Overall Length	93.5mm
OHX - Maximum Overhang	44.5mm
LSC - Clamping Length	49mm
OHN - Minimum Overhang	37.508mm
H - Shank Height	14.2mm
MHD - Mounting Hole Distance	24mm
ORDCODE	327-16B42EC-14
ADINTMS - Adaptive Interface Machine Direction	M_CYLW_G1600_1
ADINTWS - Adaptive Interface Workpiece Direction	W_CM3271_C0140_1
CNSC - Coolant Entry Style Code	1
CXSC - Coolant Exit Style Code	1
BMC - Body Material Code	2
CHANGEDATE	2022-07-14 08:31:00.000
STDLET - Standard Letter	HB
STDNO - Standard Number	DIN6535
TCDCON - Connection Diameter Tolerance	h6
DPC - Damping Property	False
DCP - Data Chip Provision	False
BBD - Balanced By Design	False
NROTF - Non Rotating Functionality	False
RTOF - Rotating Functionality	True
