Sandvik Coromant 391.21-08 50 065 VL to Whistle Notch adaptor
R 8 000,55
inc. vat
Out of stock
SKU
5759369
VL to Whistle Notch adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
VL to Whistle Notch adaptor
| CP - Coolant Pressure | 2000000Pa |
|---|---|
| DCON - Connection Diameter | 8mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 65mm |
| BD - Body Diameter | 50mm |
| LB - Body Length | 65mm |
| BHTA - Body Half Taper Angle | 0deg |
| TQ - Torque | 7Nm |
| WT - Weight Of Item | 0.59kg |
| OAL - Overall Length | 80mm |
| OHX - Maximum Overhang | 65mm |
| ORDCODE | 391.21-08 50 065 |
| ADINTMS - Adaptive Interface Machine Direction | M_VLS01_C0500_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CYLWN_F8000_1 |
| CNSC - Coolant Entry Style Code | 1 |
| CXSC - Coolant Exit Style Code | 1 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-08-27 19:15:00.000 |
| DPC - Damping Property | False |
| BBD - Balanced By Design | False |
| NROTF - Non Rotating Functionality | False |
| RTOF - Rotating Functionality | True |
