Sandvik Coromant A20S-MWLNR 06 T-Max™ P boring bar for turning

Name: Sandvik Coromant A20S-MWLNR 06 T-Max™ P boring bar for turning
SKU: 5721974
Price: 4356.20 ZAR
Availability: InStock

R 4 356,20 inc. vat

In stock

SKU

5721974

T-Max® P boring bar for turning

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

T-Max® P boring bar for turning

More Information
CP - Coolant Pressure	1000000Pa
DCON - Connection Diameter	20mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	250mm
BD - Body Diameter	20mm
TQ - Torque	3.5Nm
WT - Weight Of Item	0.57kg
OAL - Overall Length	250mm
OHX - Maximum Overhang	80mm
LSC - Clamping Length	217.7mm
KAPR - Tool Cutting Edge Angle	95deg
RMPX - Maximum Ramping Angle	0deg
DMIN - Minimum Bore Diameter	25mm
BAWS - Workpiece Side Body Angle	0deg
BAMS - Machine Side Body Angle	0deg
OHN - Minimum Overhang	32.3mm
WF - Functional Width	13mm
HF - Functional Height	0mm
GAMO - Orthogonal Rake Angle	-6deg
LAMS - Inclination Angle	-14deg
AN - Clearance Angle Major	0deg
IC - Inscribed Circle Diameter	9.525mm
RE - Corner Radius	0.79375mm
Insert Thickness	4.7625mm
H - Shank Height	18mm
ORDCODE	A20S-MWLNR 06
ADINTMS - Adaptive Interface Machine Direction	M_CYLF3_G2000_1
CNSC - Coolant Entry Style Code	1
CXSC - Coolant Exit Style Code	3
BMC - Body Material Code	1
CHANGEDATE	2022-04-07 00:39:00.000
MTP - Clamping Type Code	W
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WISO_WN0604_1
Hand	R
MIID - Master Insert Identification	WNMG 06 04 08
IFS - Insert Mounting Style Code	2
SC - Insert Shape Code	W
SSC - Insert Seat Size Code	06
CICT - Cutting Item Count	1
DPC - Damping Property	False
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	False
