Sandvik Coromant A327-16B85EC-14 Weldon to CoroMill™ 327 adaptor
Next
Sandvik Coromant A327-16B64EC-09 Weldon to CoroMill™ 327 adaptor
Previous
![Sandvik Coromant A327-16B85EC-14 Weldon to CoroMill™ 327 adaptor](https://toolcentre.co.za/media/catalog/product/cache/3d45c7c636ad12c00ca7e41150c17b7b/image/4165574f2/sandvik-coromant-a327-16b85ec-14-weldon-to-coromilltm-327-adaptor.jpg)
![Sandvik Coromant A327-16B64EC-09 Weldon to CoroMill™ 327 adaptor](https://toolcentre.co.za/media/catalog/product/cache/3d45c7c636ad12c00ca7e41150c17b7b/image/4164606e5/sandvik-coromant-a327-16b64ec-09-weldon-to-coromilltm-327-adaptor.jpg)
R 7 703,85
inc. vat
In stock
SKU
5722482
Weldon to CoroMill® 327 adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
Weldon to CoroMill® 327 adaptor
CP - Coolant Pressure | 2000000Pa |
---|---|
DCON - Connection Diameter | 12mm |
KAP - Kappa (z-axis Rot) | 0deg |
LF - Functional Length | 154.3mm |
BD - Body Diameter | 12mm |
LB - Body Length | 83.11mm |
BHTA - Body Half Taper Angle | 30deg |
TQ - Torque | 6.5Nm |
RPMX - Rotational Speed Maximum | 300001/min |
WT - Weight Of Item | 0.37kg |
OAL - Overall Length | 154.3mm |
OHX - Maximum Overhang | 101.515mm |
LSC - Clamping Length | 52.7mm |
OHN - Minimum Overhang | 83.11mm |
H - Shank Height | 14.22mm |
MHD - Mounting Hole Distance | 24.209375mm |
ORDCODE | A327-16B85EC-12 |
ADINTMS - Adaptive Interface Machine Direction | M_CYLW_R6250_1 |
ADINTWS - Adaptive Interface Workpiece Direction | W_CM3271_C0120_1 |
CNSC - Coolant Entry Style Code | 1 |
CXSC - Coolant Exit Style Code | 1 |
BMC - Body Material Code | 2 |
CHANGEDATE | 2022-02-09 13:52:00.000 |
STDLET - Standard Letter | HB |
STDNO - Standard Number | DIN6535 |
TCDCON - Connection Diameter Tolerance | h6 |
DPC - Damping Property | False |
DCP - Data Chip Provision | False |
BBD - Balanced By Design | False |
NROTF - Non Rotating Functionality | False |
RTOF - Rotating Functionality | True |
