Sandvik Coromant A392.41006-63 19 220A HSK to arbor damped adaptor
R 89 122,70
inc. vat
Out of stock
SKU
5722853
HSK to arbor damped adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
HSK to arbor damped adaptor
| CP - Coolant Pressure | 2000000Pa |
|---|---|
| DFC - Functional Diameter | 48.01mm |
| DCON - Connection Diameter | 19.05mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 220mm |
| BD - Body Diameter | 63mm |
| LB - Body Length | 220mm |
| BHTA - Body Half Taper Angle | 0deg |
| TQ - Torque | 20Nm |
| WT - Weight Of Item | 3753.5g |
| OAL - Overall Length | 252mm |
| OHX - Maximum Overhang | 220mm |
| ORDCODE | A392.41006-63 19 220A |
| ADINTMS - Adaptive Interface Machine Direction | M_HSK01_C0630_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_FDA1AB1_R7500_1 |
| CNSC - Coolant Entry Style Code | 1 |
| CXSC - Coolant Exit Style Code | 1 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-08-27 19:09:00.000 |
| STDLET - Standard Letter | A |
| STDNO - Standard Number | DIN69893-1 |
| DPC - Damping Property | False |
| BBD - Balanced By Design | False |
| NROTF - Non Rotating Functionality | False |
| RTOF - Rotating Functionality | True |
