Sandvik Coromant C10-LC140-205L VDI to Coromant Capto™ clamping unit
R 54 784,85
inc. vat
Out of stock
SKU
6251588
VDI to Coromant Capto® clamping unit
Reliable nationwide shipping
Delivery in 4 - 5 days
VDI to Coromant Capto® clamping unit
| CP - Coolant Pressure | 8000000Pa |
|---|---|
| DFC - Functional Diameter | 72mm |
| DCON - Connection Diameter | 100mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 90mm |
| TQ - Torque | 285Nm |
| WT - Weight Of Item | 50.87kg |
| OAL - Overall Length | 159mm |
| OHX - Maximum Overhang | 90mm |
| BAWS - Workpiece Side Body Angle | 0deg |
| WF - Functional Width | 205mm |
| HF - Functional Height | 0mm |
| LPR - Protruding Length | 153mm |
| OAH - Overall Height | 140mm |
| OAW - Overall Width | 350mm |
| ORDCODE | C10-LC140-205L |
| ADINTMS - Adaptive Interface Machine Direction | M_PMD01_A1400_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CCS02_C1000_1 |
| CNSC - Coolant Entry Style Code | 2 |
| CXSC - Coolant Exit Style Code | 1 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-04-01 14:22:00.000 |
| STDNO - Standard Number | ISO26623-2 |
| Hand | L |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
