Sandvik Coromant C3-391.60B-01 095A Coromant Capto™ to floating rubber collet chuck
R 12 238,30
inc. vat
In stock
SKU
5726983
Coromant Capto® to floating rubber collet chuck
Reliable nationwide shipping
Delivery in 4 - 5 days
Coromant Capto® to floating rubber collet chuck
| DFC - Functional Diameter | 22mm |
|---|---|
| DCON - Connection Diameter | 23mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 95mm |
| BD - Body Diameter | 32mm |
| LB - Body Length | 95mm |
| BHTA - Body Half Taper Angle | 0deg |
| RPMX - Rotational Speed Maximum | 80001/min |
| WT - Weight Of Item | 507.2g |
| OAL - Overall Length | 114mm |
| OHX - Maximum Overhang | 95mm |
| TFLA - Tap Floating Length Ahead | 10mm |
| TFLB - Tap Floating Length Behind | 2mm |
| ORDCODE | C3-391.60B-01 095A |
| ADINTMS - Adaptive Interface Machine Direction | M_CCS01_C0320_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CLTRFX_C0230_1 |
| CNSC - Coolant Entry Style Code | 3 |
| CXSC - Coolant Exit Style Code | 0 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2021-12-21 06:30:00.000 |
| STDNO - Standard Number | ISO26623-1 |
| DPC - Damping Property | False |
| DCP - Data Chip Provision | False |
| NROTF - Non Rotating Functionality | False |
| RTOF - Rotating Functionality | True |
