Sandvik Coromant C6-CP-25BR-45065-11B CoroTurn™ Prime cutting unit for turning

Name: Sandvik Coromant C6-CP-25BR-45065-11B CoroTurn™ Prime cutting unit for turning
SKU: 7100732
Price: 7598.05 ZAR
Availability: InStock

Be the first to review this product

R 7 598,05 inc. vat

In stock

SKU

7100732

CoroTurn® Prime cutting unit for turning

Reliable nationwide shipping

Delivery in 4 - 5 days

Details

CoroTurn® Prime cutting unit for turning

More Information

More Information
CP - Coolant Pressure	15000000Pa
DFC - Functional Diameter	44mm
DCON - Connection Diameter	63mm
KAP - Kappa (z-axis Rot)	0deg
LF - Functional Length	65mm
TQ - Torque	4Nm
WT - Weight Of Item	1.075kg
OAL - Overall Length	103mm
OHX - Maximum Overhang	65mm
KAPR - Tool Cutting Edge Angle	25deg
RMPX - Maximum Ramping Angle	23deg
DMIN - Minimum Bore Diameter	280mm
BAWS - Workpiece Side Body Angle	0deg
BAMS - Machine Side Body Angle	0deg
WF - Functional Width	45mm
HF - Functional Height	0mm
GAMO - Orthogonal Rake Angle	0deg
LAMS - Inclination Angle	0deg
IC - Inscribed Circle Diameter	11mm
RE - Corner Radius	0.79375mm
Insert Thickness	5mm
APMX - Depth Of Cut Maximum	3mm
ORDCODE	C6-CP-25BR-45065-11B
ADINTMS - Adaptive Interface Machine Direction	M_CCS01_C0630_1
CNSC - Coolant Entry Style Code	3
CXSC - Coolant Exit Style Code	3
BMC - Body Material Code	1
CHANGEDATE	2022-08-10 09:37:00.000
STDNO - Standard Number	ISO26623-1
MTP - Clamping Type Code	D
CUTINT_MASTER - Part 2 Of Cutting Item Interface Identifiers	WCOR_TLB11_1
Hand	R
MIID - Master Insert Identification	CP-B1108
IFS - Insert Mounting Style Code	2
SSC - Insert Seat Size Code	CP-B11
CICT - Cutting Item Count	1
DPC - Damping Property	False
NROTF - Non Rotating Functionality	True
RTOF - Rotating Functionality	False
