Sandvik Coromant CNMG 16 06 08-WMX 3210 T-Max™ P insert for turning
Next
Sandvik Coromant CCMT 09 T3 04-WF 5015 CoroTurn™ 107 insert for turning
Previous
R 385,25
inc. vat
In stock
SKU
5724775
T-Max® P insert for turning
Reliable nationwide shipping
Delivery in 4 - 5 days
T-Max® P insert for turning
KAP - Kappa (z-axis Rot) | 0deg |
---|---|
WT - Weight Of Item | 0.02kg |
AN - Clearance Angle Major | 0deg |
IC - Inscribed Circle Diameter | 15.875mm |
RE - Corner Radius | 0.7938mm |
Insert Thickness | 6.35mm |
D1 - Fixing Hole Diameter | 6.35mm |
LE - Cutting Edge Effective Length | 15.3199mm |
L - Cutting Edge Length | 16.1199mm |
KRINS - Major Cutting Edge Angle | 95deg |
BS - Wiper Edge Length | 0.9mm |
ORDCODE | CNMG 16 06 08-WMX 2015 |
CHANGEDATE | 2021-12-17 17:04:00.000 |
Hand | N |
IFS - Insert Mounting Style Code | 2 |
SC - Insert Shape Code | C |
SSC - Insert Seat Size Code | 16 |
CUTINT_SIZESHAPE - Insert Size And Shape | MISO_CN1606_1 |
Grade | 2015 |
COATING | CVD TiCN+Al2O3+TiN |
SUBSTRATE | HC |
CBMD - Chip Breaker Manufacturer's Designation | WMX |
CEDC - Cutting Edge Count | 4 |
WEP - Wiper Edge Property | True |
