Sandvik Coromant 935-C8-EF25-090 Coromant Capto™ to CoroChuckâ„¢ 935

R 22 471,00 inc. vat
In stock
SKU
7472576
Coromant Capto® to CoroChuck™ 935
Reliable nationwide shipping
Delivery in 4 - 5 days
Coromant Capto® to CoroChuck™ 935
More Information
CP - Coolant Pressure 8000000Pa
DFC - Functional Diameter 55mm
DCON - Connection Diameter 25mm
KAP - Kappa (z-axis Rot) 0deg
LF - Functional Length 90mm
BD - Body Diameter 80mm
LB - Body Length 90mm
BHTA - Body Half Taper Angle 0deg
TQ - Torque 10Nm
WT - Weight Of Item 2.737kg
OAL - Overall Length 138mm
OHX - Maximum Overhang 90mm
LSC - Clamping Length 100mm
ORDCODE 935-C8-EF25-090
ADINTMS - Adaptive Interface Machine Direction M_CCS02_C0800_1
ADINTWS - Adaptive Interface Workpiece Direction W_CYLH_G2500_1
CNSC - Coolant Entry Style Code 3
CXSC - Coolant Exit Style Code 1
DCPS - Data Chip Provision Size 2
BMC - Body Material Code 1
CHANGEDATE 2022-06-20 10:21:00.000
STDNO - Standard Number ISO26623-1
DPC - Damping Property False
DCP - Data Chip Provision True
BBD - Balanced By Design False
NROTF - Non Rotating Functionality True
RTOF - Rotating Functionality False
