Sandvik Coromant C4-391.60B-02 101A Coromant Capto™ to floating rubber collet chuck
R 14 847,65
inc. vat
In stock
SKU
5728503
Coromant Capto® to floating rubber collet chuck
Reliable nationwide shipping
Delivery in 4 - 5 days
Coromant Capto® to floating rubber collet chuck
| DFC - Functional Diameter | 28mm |
|---|---|
| DCON - Connection Diameter | 28mm |
| KAP - Kappa (z-axis Rot) | 0deg |
| LF - Functional Length | 101mm |
| BD - Body Diameter | 40mm |
| LB - Body Length | 101mm |
| BHTA - Body Half Taper Angle | 0deg |
| RPMX - Rotational Speed Maximum | 80001/min |
| WT - Weight Of Item | 0.7kg |
| OAL - Overall Length | 125mm |
| OHX - Maximum Overhang | 101mm |
| TFLA - Tap Floating Length Ahead | 10mm |
| TFLB - Tap Floating Length Behind | 2mm |
| ORDCODE | C4-391.60B-02 101A |
| ADINTMS - Adaptive Interface Machine Direction | M_CCS01_C0400_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CLTRFX_C0280_1 |
| CNSC - Coolant Entry Style Code | 3 |
| CXSC - Coolant Exit Style Code | 0 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2021-12-21 06:30:00.000 |
| STDNO - Standard Number | ISO26623-1 |
| DPC - Damping Property | False |
| DCP - Data Chip Provision | False |
| NROTF - Non Rotating Functionality | False |
| RTOF - Rotating Functionality | True |
